Network diagram viz for dashboard studio

siv
Explorer
‎07-20-2025 04:29 AM

What are the options i have for diagram in dashboard studio?

I have version 9.1.8

Labels (2)
0 Karma
Reply

siv
Explorer
‎07-20-2025 11:07 AM

Its not make any sense there is no option for this diagram and support for this...
I need read more about this Link Graph.
What is the best way to build a diagram for network (ip,vip,fw,subnet...)

0 Karma
Reply

kiran_panchavat
SplunkTrust
SplunkTrust
‎07-20-2025 06:16 AM

@siv

Dashboard Studio does not support custom visualizations (like Network Diagram Viz from Splunkbase). These visualizations are only supported in Classic (Simple XML) dashboards.

If you want to stay in Dashboard Studio, use the built-in Link Graph like this

Network_2025-07-20 at 05.16.42+0400_Splunk.png





Did this help? If yes, please consider giving kudos, marking it as the solution, or commenting for clarification — your feedback keeps the community going!
Reply
