Editing the other value for a pie chart

Abass42
Communicator

I have a query that is executing a stats count by source type, as we want to see how many sensitive files leave our firm and the quantity. I am doing an appendcols and then transposing


In the dashboard, the pie chart look like:






index=fortinet dlpextra IN (WatermarkBlock1,Log_WatermarkBlock2,Log_WatermarkBlock3,Log_WatermarkBlock4)  | lookup DataF.csv dlpextra OUTPUT C_Label as C_Label
| stats count as Proxy
| appendcols
    [search index=iron AutomaticClassification
| lookup IPort_Class.csv DLP_Class OUTPUT C_Label as C_Label
| stats count as Email]

| appendcols
    [search index=035 "Common.DeviceName"="p151.d.com" OR Common.DeviceName="p1p71.c.com" "SensitiveInfoTypeData{}.SensitiveInfoTypeName"=*
| table SensitiveInfoTypeData{}.SensitiveInfoTypeName
| stats count as SFTP
]
| appendcols
    [search index=testing sourcetype="net:alert" dlp_rule="AZ C*"
| eval dlp_rule=replace(dlp_rule, "AB", "")
| stats count as Netskope]
| transpose
| rename "row 1" as Count

My question is, how would you edit the Splunk query to rename the column name to the value I provided instead of Other.

DO i even need a transpose? That has been the best way I have found for creating a pie chart out of different data sources.

Preferably, id like to understand how to do that with the JSON formatting I get with Dashboard studio, as well as figure out how to do it inline, within the query.



Thanks



Labels (2)
0 Karma

richgalloway
SplunkTrust
SplunkTrust

Try this query that does not use appends or transpose.

(index=fortinet dlpextra IN (WatermarkBlock1,Log_WatermarkBlock2,Log_WatermarkBlock3,Log_WatermarkBlock4))
OR (index=035 "Common.DeviceName"="p151.d.com" OR Common.DeviceName="p1p71.c.com" "SensitiveInfoTypeData{}.SensitiveInfoTypeName"=*)
OR (index=iron AutomaticClassification)
OR (index=testing sourcetype="net:alert" dlp_rule="AZ C*")
| eval type = case(index=fortinet, "Proxy",
                   index=iron, "Email",
                   index=035, "SFTP",
                   index=testing, "Netskope",
                   1==1, "Unknown")
| stats count by type
---
If this reply helps you, Karma would be appreciated.
0 Karma

Abass42
Communicator

I am working on implementing this query, but I need to rename and standardize the output to the C_Label values so i can stats count on those. I need a count per source. I dont think i cram my eval statements with the OR statements. Ill try to incorporate this in my query



Thanks
